SH-613
UNIVERSAL HIGH SPEED CRUSHING MACHINE
  • Put granulated sugar in thisalmighty crusher to crush it into the finest powder at 200 Mash.
  • This machine is consisted of 24 pcs of sheet, and there is magnet equipped inside. If any impurities in the granulated sugar, they will be collected by the magnet. RPM:7200,output is 50 kg for 10 minutes. Machine outshell is all made of aluminum alloy, and the hopper is made by stainless steel to be clean & beautiful.
  • Output=50kgs/10minute
  • Machine size:L100xW950Xh1720mm
  • Machine weight:400Kgs.
  • Horse power:5HP.

SH-300
DOUBLE LAYER WARMING AND MIXING MACHINE
  • Machine size:L1000xW1000xH1900mm
  • Machine capacity:100Kgs.
  • Machine weight:1200Kgs.
  • Horse power:1HP

SH-300A
DOUBLE LAYER WARMING AND MIXING MACHINE

  • Machine size:L1700xW1700xH2300mm.
  • Machine capacity:3000Kgs.
  • Horse power:3HP.

SH-400
STEAM MELTING AND MIXING MACHINE
  • It is rigid with 25HP, doublelayer instasllation provide the warm water & steam, easy stirring. Interior is made by stainless steel.
  • Hydraulic device is equipped on to control the height.
  • Machine size:L1860xW2130 xH1110mm.
  • Machine weight:2000Kgs.
  • Horsepower:25HP.

SH-404A
3-4OLLING MILLS MACHINE
  • This machine grind & mix chocolate.
  • Machine size:L1720xW2460xH1220mm
  • Machine weight:2200Kgs.
  • Horse power:25HP.
  • Capacity:2000Kgs/8HRS.




SH-301
WARMING WATER 2-PLY PUMP
  • Convey and warming the chocolate.
  • Machine size:L1000xW500xH500mm
  • Machine weight:70Kgs.
  • Horse power:2HP.

SH-403
REFINERY MACHINE
  • The surface which contact with chocolate were made of granite.
  • Grinding, deoxidize, deodorize increase the chocolate smell well.
  • Machine size:L1800xW1800xH1850mm.
  • Machine weight:3000 Kgs.
  • Horsepower:15Hp (4KW).



SH-401.1
VIBRATOR CONVEYOR
  • Machine sizeL1700xW800xH1000mm.
  • Machine weight:2500kgs.
  • Electronic:3KW.
  • Vlbrate the mould and make the chocolate without air bubble.

SH-401
CHOCOLATE FILLING MACHINE
  • Just change the shape mould, can be produce many kind shape chocolate.
  • Machine size: L1100 x W960 x H1800 mm
  • Machine weight:800kgs.
  • Electronic:4KW.
  • Capacity:13kgs/minute

SH-411
AUTOMATIC TEMPERING MACHINE
  • Machine size:L1200xW1000xH2145mm
  • Machine weight:1200Kgs.
  • Horse power:1HP,3kw Heater
  • Machine capacity:300Kgs/hr.

@

@


SH-410
CHOCOLATE ROLLER FORMING MACHINE
SH-410A Bean Shape
SH-410B Ball Shape
SH-410C Rugby Shape
  • Machine size: L1200 x W700 x H1560mm.
  • Machine weight:2500Kgs.
  • Horse power:2HP.
  • Capacity:as belows.

@

TYPE ROLLER WIDE ROLLERQ'TY CAPACITY kgs/hr
400-1 400 1 125
400-2 400 2 250
600-1 600 1 187
600-2 600 2 375
600-3 600 3 562

SH-410-1
CHOCOLATE SELECTION MACHINE
  • This machine connect with the conveyer.
  • Maachine size:L1380xW680 xH980mm.
  • Machine weight:500Kgs.
  • Horse power:1/4 HP.

@



FLOW SHEET OF CHOCOLATE PASTE MANUFACTURING PROCESS.
